Kẹp gắp chân không điện VGP20 có tải trọng cao

VGP20 Vacuum Gripper

Request Quote Add to Request

Category: OnRobot

100% Genuine & Brand New Products

Official Manufacturer Warranty

Guaranteed Authenticity

After-Sales Service Support by Servo Dynamics

Fast Delivery Support on the Same Day*

*For all in-stock products

Description
Additional information

Product Information

The VGP20 electric vacuum gripper is designed for carton palletizing and offers up to 90% lower operating costs compared to pneumatic grippers.

Versatile Material Handling:

Handles various materials, including thin-walled cardboard boxes, foam, shipping bags, and challenging shapes.

Easy Deployment, Intelligent Operation:

Integrated intelligence, multi-channel functionality, and compatibility with leading robot brands simplify deployment and operation.

Key Advantages:

Powerful Performance: Handles a wide range of materials.
Flexible Customization: Changeable suction cups and adjustable gripper arms.
Cost Savings: Up to 90% lower operating and maintenance costs vs. pneumatic grippers.
Easy Deployment: Compatible with all leading robot brands and features user-friendly software.
Safe Operation: Continuous airflow monitoring with automatic stop and alerts.

Technical Specifications

Parameter	Minimum	Average	Maximum	Unit
Vacuum	5% (-0.05 bar / 1.5 inHg)	–	60% (-0.607 bar / 17.95 inHg)	% / Bar / inHg
Total Airflow	0	–	48	L/min
Airflow per Channel	0	–	12	L/min
Payload (with default accessories)	–	10 kg (22.04 lb) (1) / 20 kg (44.09 lb) (2)	–	kg / lb
Number of Suction Cups	1	16	24 (5)	pcs
Grip Time (at 40% vacuum)	–	0.25 s (3)	–	s
Release Time	–	0.4 s (3)	–	s
Noise Level (4)	–	67	71	dB(A)
Vacuum Pump	Integrated, electric BLDC
Dust Filter	Integrated, replaceable 50µm
IP Rating	IP54 (6)
Dimensions			264 x 184 x 92 mm (10.39 x 7.24 x 3.62 inch)	mm / inch
Weight			2.55 kg (5.62 lb)	kg / lb

Notes:

(1) 10 kg payload with standard cardboard boxes using all suction cups.
(2) 20 kg payload requires low acceleration (total 1.2G). Other conditions may apply.
(3) Smaller/fewer suction cups result in shorter grip times. Release time is load-dependent.
(4) See “Noise Level” section for details.
(5) Using the High Load Backplate (accessory).
(6) Never use in wet environments (especially CNC with cutting fluids).
