Available Communication Options for PanelView Plus Terminals

Summary

Available Communication Options for PanelView Plus Terminals

Content

Question

What communication options are available on the PanelView Plus Terminals?

Answer

Most PanelView Plus terminals support RS-232 serial (DF1/DH-485) and Ethernet/IP via their built-in ports.

Note: If RS-485 serial DH-485 is needed, see the applicable communication card below. For more information on RS-232 versus RS-485 electrical standards and DF1 versus DH-485 protocols see IN78 – Standards and Differences between DF1 and DH-485.

PanelView Plus 6 400 – 600 terminals, and PanelView Plus 7 Terminals:

• No add-on communication cards are supported.
• For PanelView Plus 7 Serial Communication, you would need an additional cable, refer to QA29511 – USB to Serial converters for PanelView Plus 7.

For PanelView Plus 700 – 1500 and PanelView Plus 6 700 – 1500 terminals:

• Note: All PanelView Plus 6 terminals have an Ethernet port. The cat. no. 2711P-RN20 module provides an additional Ethernet port on PanelView Plus 6 700 – 1500 terminals f/w 6.10.17 and higher.

For PanelView Plus 700-1500 terminals:

• The 2711P-RN10C DeviceNet module uses an open style 5-pin linear connector without jack screws, catalog number: 1799-DNETCON
• The 2711P-RN10H DeviceNet module uses an open style 5-pin linear connector with jack screws, catalog number: 1799-DNETSCON
• For information on additional DeviceNet open-style connectors see technote QA1013 – Allen-Bradley Open-Style DeviceNet Connector Part Numbers and Descriptions

For PanelView Plus 400-600 terminals:

For more detailed information please refer to the Visualization Solutions Selection Guide Publication VIEW-SG001.

Note: Rockwell Automation currently supplies Catagory 5e and 6 ethernet cables per document Ethernet Media Specifications

Source: Rockwell Automation’s Technote database.
