ztC Edge

ztC Edge 200i
ztC Edge 250i

Compute: Intel Xeon W-1250TE, 2.4 GHz, 12 MB cache, 6 HT cores
Memory: 32 GB DDR4, 2666 MHz (ECC)
Storage: 1 TB SSD (NVMe)
Networking: 2 x 1 GbE (for a-links), 4 x 1 GbE (for networks)
Operating Temperature: –20 to 60 °C (–4 to 140 °F)
Humidity: 95% @ 40 °C (non-condensing)
Shock and vibration: 20G, 11 ms, 3 Grms @ 5 – 500 Hz
Input power: 9V – 36V (DC)
Dimensions: 230 x 192 x 77 mm (9.1 x 7.6 x 3.0 in)
Weight: 3.3 kg (7.2 lbs)
Availability support: High availability
Certifications: CI D2, FCC, CE and others
Host OS support: Stratus Redundant Linux
Guest OS support: Windows and Linux

Compute: Intel Xeon W-1290TE, 1.8 GHz, 20 MB cache, 10 HT cores
Memory: 64 GB DDR4, 2666 MHz (ECC)
Storage: 2 TB SSD (NVMe)
Networking: 2 x 1 GbE (for a-links), 6 x 1 GbE (for networks)
Operating Temperature: –20 to 60 °C (–4 to 140 °F)
Humidity: 95% @ 40 °C (non-condensing)
Shock and vibration: 10G, 11 ms, 1.5 Grms @ 5 – 500 Hz
Input power: 9V – 36V (DC)
Dimensions: 230 x 192 x 127 mm (9.1 x 7.6 x 5.0 in)
Weight: 4.6 kg (10.2 lbs)
Availability support: Fault tolerance and high availability
Certifications: CI D2, FCC, CE and others
Host OS support: Stratus Redundant Linux
Guest OS support: Windows and Linux
