Name: FA-106R - Six Zone Conventional Fire Alarm Control Panel - Servodynamics
Price: 7000000 VND
Availability: InStock

Model	FA-106R
Manufactures	Mircom
Origin	Canada
Standards	Meets latest ULC S-527-2011 Standard
Led	A.C. ON LED (Green) – Zone Alarm LED (Amber) – Signal Trouble LED (Amber) – Ground Fault LED (Amber) – Battery Fault LED (Amber) – Alarm Silenced LED (Amber) – Common Trouble LED & Silence button
Standard Features	Six Class ‘B’ Input circuits
	Two Class ‘B’ Output circuit (2.0Amps)
	Signal Silence
	Audible tones are DIP Switch selectable for Steady and Temporal Code
	Powerful 3 mA capacity per zone for 2-wire smoke detectors
	Common alarm Relay contact, Form C, 28 VDC @ 3 AMP (Resistive)
	Common trouble Relay contact, Form C, 28 VDC @ 3 Amp (Resistive)
	Remote Trouble Indicator output
	Selectable 1 minute Signal silence inhibit
	Extensive Transient Protection on all circuits
	All circuits are power limited
	Fully regulated 24 VDC Auxiliary Power, 250mA maximum
	All configurations performed by DIP switch
	It comes with a durable CAT-30 lock and key
	Space is provided for 5 to 7.0 AH batteries
Input Circuits	– Output Voltage: 24 VDC, fully regulated – Current Limited: 50 mA – Supervisory Current: 3 mA (up to 30, 2-wire smoke detectors @ 100 uA each) – End of Line Resistor: 3.9Kohm ± 5%, 1/2W
Output Circuits	– Output Voltage: 24 VDC (FWR) – Output Current: 2.0A (1.25A max per circuit) – Auxiliary Contacts: 28 VDC, 3A (Resistive) – End of Line Resistor: 3.9Kohm ± 5%, 1/2W – Auxiliary Power: 250mA
Dimensions	13.7” (347mm) W x 12.7” (322mm) H x 2.8” (71mm) D

FA-106R – Six Zone Conventional Fire Alarm Control Panel

Model: FA-106R
Origin: Canada
Certifications: UL, ULC
Retail price: 7,000,000 VND (VAT not included)
